36V 48V 60V 72V 500W-1000W Universal 3-Mode Sine Wave Brushless

intelligent brushless sine wave controller for electric bike/electric scooter/brushless motor

if motor not have hall wire，not connect hall wires also can work

Voltage：36V/42V/48V/52V/60V/72V/84V universal

Current：26A-33A

Transistor: 12

Phase angle: 60 °/120 ° all can be used

Rated power：500W-800W-1000W all can work

3.PAS(pedal assist)

（self-learnig line ）

（throttle）

how to connect ？

(color to color）

2. connect the battery line(red wire :battery + , black:battery-)

3. connect the controller throttle line（color to color），connect electric door lock

（if your throttle not have electric door lock，controller electric door lock can be shorted）

4. connect the hall line(if motor without hall line, don't need connect)

, the wheel will forward or reverse.

(,Separate the self-learning line.

, Separate the self-learning line. Docking the self-learning line again，

if wheel forward ,Separate the self-learning line.)

48V/52V/60V/64V/72V 26-33A 500-1000W 60°/120° Phase Angle Universal Brushless Controller

Product parameters:

Color: golden

Condition: 100% brand new

Item type: Motor Controller

Material: Aluminium alloy

Voltage: 48V-52V-60V-64V-72V

Weight: about 588g

Power: 500W-1000W

Current limit: 26A-33A

12-tube sinusoid controller,Normal Instrument line, a Sine wave model only can work with hall sensored brushless DC motor .

If motor doesn't have hall sesnor or hall sensor is damage .it is square wave controller .

1. 48V, 60V, 64V,72V, universal

2. One-line instrumentation adds more adaptability, about 80%.

3. In terms of hardware: thicker aluminum shell, better heat dissipation. The motherboard solution is better. Power tubes, capacitors, copper bars, etc. are better.

4.Suitable Motor Phrase Angle: 60°/120° Phase Angle Universal

5.Suitable for: electric bicycle, scooter,Small tricycle,Two-wheeler etc

controller function：

(generally not used)

(generally not used)

4.3-speed (low/middle/high speed)

6. one-line LCD meter

7. hall LCD meter

(PAS)

9. alarm power supply

10. alarm signal

11. cruise

12. reverse

15. Phase Velocity Meter Line

How to connect controller？

(color to color)

2. connect the battery line(red:+ , black:-)

3. connect the controller throttle line, electric lock（if throttle not have electric lock,controller electric lock docking,if controller electric lock is 1 wire,can connect to battery + ）

4. connect the hall line(if motor without hall line, don't need connect)

, the wheel will forward or reverse.

(,Separate the self-learning line.

, Separate the self-learning line. Docking the self-learning line again,if wheel forward ,Separate the self-learning line.)
